350 × 150mm UVLED surface light curing machine
| Function configuration |
Technical parameters |
| Product Name |
UVLED curing lamp |
| Product model |
F20-350150L36-001 F20-350150L38-001、F20-350150L39-001、F20-350150L40-001 |
| Lamp head size |
L391mm×W170mm×H248mm |
| Controller size |
L480mm×W300mm×H420mm |
| Irradiation power |
>700mW/cm2 (distance 1cm) |
| Irradiation energy |
>2300mJ/cm2 (speed: 2m/min) |
| Power |
800W per unit |
| Wavelength |
365nm, 385nm, 395nm, 405nm |
| Number of LED beads |
360 pieces |
| Illumination area |
150mm×300mm |
