| Product model: | RX200-1 | RX300-1 | RX400-1 | RX200-2 | RX300-2 | RX400-2 |
| Whole machine power: | 1.2KW | 2.2KW | 3.2KW | 2.2KW | 4.2KW | 6.2KW |
| Single lamp power: | 1KW | 2KW | 3KW | 1KW | 2KW | 3KW |
| Number of Lamp Tubes: | 1 unit | 2 unit | ||||
| Lamp type: | Mercury lamp/halogen lamp optional | |||||
| Illumination method: | Top down illumination | |||||
| Illumination distance: | 50-200（mm）Height adjustable | |||||
| Dimensions (cm): | 100*41*84 | 100*51*91 | 100*65*92 | 120*45*84 | 120*55*95 | 150*65*91 |
| Mesh belt width: | 200mm | 300mm | 400mm | 200mm | 300mm | 400mm |
| Mesh belt material: | Teflon mesh belt | |||||
| Conveyor speed: | 0.5-8M/min(meters per minute) | |||||
| Power regulation: | All-optical | |||||
| Input power supply: | AC 220V 50/60Hz | |||||
| Does it support customization | Support customization | |||||
| Inventory status: | Regular inventory | |||||
| Equipment usage: | Sampling and small batch production: ink curing for screen printing, pad printing, printing, etc; Curing of adhesives such as plastic, metal, and glass; Spray coating and oil curing. | |||||
